Automatic Rock Wool Panel Production Line with 40~120 meters/min Conveying Speed and 2800mm Swing Belt Width

Automatic Rock Wool Panel Production Line with 40~120 meters/min Conveying Speed and 2800mm Swing Belt Width

Markenbezeichnung:	Greens
Modellnummer:	Maschine zur Herstellung von Wandpaneelen aus Steinwolle
MOQ:	1
Preis:	US $2000000-4000000
Zahlungsbedingungen:	L/c, t/t

Einzelheiten

Beschreibung des Produkts

Einzelheiten

Herkunftsort:

Hebei

Produktname:

Maschine zur Herstellung von feuerfesten, hitzebeständigen und schalldämmenden Wandpaneelen aus Stei

Stichwort:

Steinwolle-Gebäudewand-Zwischenschicht-Innendämmungswand-Steinwolle-Produktionslinie

Stromspannung:

380 V oder angepasst

Geschwindigkeit vermitteln:

40 bis 120 m/min

Schwungriemenbreite:

2800 mm

Schwinggurtmotor:

4 kW (Variablen Frequenzmotor)

Tafeldicke:

20-250mm

Platten-Dichte:

30-250 kg/m³

Hervorheben:

fireproof rock wool wall panels machine

heat preservation mineral wool production line

sound insulation rock wool board maker

Beschreibung des Produkts

Fireproof Heat Preservation Sound Insulation Rock Wool Wall Panels Making Machine

This advanced production line combines fireproofing, heat preservation, and sound insulation capabilities for manufacturing high-quality rock wool wall panels with automated efficiency.

Key Specifications

Attribute	Value
Product Name	Drum Collection Machine Wool Collecting And Pendulum System Rock Wool Production Line
Voltage	380v Or Customized
Electric Control	PLC control
Condition	New
Conveying speed	40~120 meters/min
Swing belt width	2800mm
Swing belt motor	4kw (variable frequency motor)

Technical Specifications

Product Name: Rockwool Panel Production Line
Automatic Grade: Automatic
Voltage: 380V
Panel Thickness: 30-200mm
Felt Size: 1000mm (adjustable)
Panel Density: 30-200 Kg/m3
Applicable Industries: Manufacturing Plant, Retail, Construction works
Finished products: Rock wool board
Usage: Building Material Production

System Components

Slag and cotton separation system
Cotton collection mechanism
Screen cleaning device
Cotton lifting system
Automatic refueling and lubrication system
Automatic slag discharge device

The machine features a sturdy steel structure frame with bearing transmission system. The drum includes a mesh plate with installed negative pressure air induction chamber beneath. The fan creates negative pressure in the induction chamber, effectively pulling cotton fibers onto the stencil while filtering and emptying through the settling chamber.
