Fully Automatic Plasterboard Laminating Machine with 1300mm Effective Lamination Width and 3-15m/min Adjustable Speed for Gypsum Ceiling Tile Production

Fully Automatic Plasterboard Laminating Machine with 1300mm Effective Lamination Width and 3-15m/min Adjustable Speed for Gypsum Ceiling Tile Production

Markenbezeichnung:	LVJOE
Modellnummer:	FM1300
MOQ:	1 Linie
Preis:	US $20000-200000
Zahlungsbedingungen:	L/C, T/T
Versorgungsfähigkeit:	10 Zeilen pro Jahr

Einzelheiten

Beschreibung des Produkts

Einzelheiten

Herkunftsort:

Hebei, China

Zertifizierung:

ISO,CE

Anwendung:

Deckenplatten aus Gips herstellen

Geschwindigkeit:

3–15 m/min (einstellbar)

Laminat-Typ:

Simplex oder doppelte Seite

Leistung:

100KW

Effektive Laminierungsbreite:

1300 mm

Brettzuführungs- und -freigabemodus:

Automatisch/Handbuch

Gewicht:

20t

Stromspannung::

380V. 50 Hz

Produktname:

Hochwertiger Fabriklieferant, maßgeschneiderte wasserdichte, vollautomatische Gipskarton-Trockenbaum

Stichwort:

Gipskarton-Laminierer

Verpackung Informationen:

Standardpaket

Versorgungsmaterial-Fähigkeit:

10 Zeilen pro Jahr

Hervorheben:

1300mm Effective Lamination Width Plasterboard Laminating Machine

3-15m/min Adjustable Speed Gypsum Ceiling Tile Production Line

Fully Automatic Operation Drywall Machine

Beschreibung des Produkts

High Quality Factory Supplier Customized Waterproof High-capacity Fully Automatic Plasterboard Drywall Machine

Our PVC gypsum ceiling tile production line creates environmentally friendly, lightweight ceiling boards with excellent fireproof, waterproof, and corrosion-resistant properties. The tiles feature a paper-faced gypsum core with PVC surface layer and aluminum foil backing, making them ideal for demanding environments.

Key Specifications

Attribute	Value
Application	Gypsum ceiling tile production
Speed	3-15m/min (adjustable)
Laminate type	Single side or double side
Power	100KW
Effective lamination width	1300mm
Board feeding/releasing mode	Automatic/manual
Weight	20T
Voltage	380V, 50HZ

Key Features

Daily Capacity: 7,000-12,000m² (based on 595×595×7mm boards)
Automation Level: Simple operation with high automation
Material Options: Gypsum board, PVC film, aluminum foil, and specialized adhesives
Customizable Dimensions: Available in 595×595mm, 600×600mm, 603×603mm, and 1200×600mm sizes
Surface Patterns: Fully customizable designs

Production Process Flow

Automatic feeding → dust cleaning → PVC film/aluminum foil laminating → film cutting (manual/automatic) → conveying → vertical cutting (with dust collection) → horizontal cutting (with dust collection) → small board stacking → edge sealing → stretch packing → finished products stacking

Technical Parameters

Parameter	Specification
Sheet thickness	5-30mm
Laminating speed	15m/min
Speed adjustment	Frequency conversion synchronous speed regulating
Electrical control	PLC
Annual capacity	2-4 million m²
Compatible materials	PVC baseboard, gypsum board, wood board, sectional board, PVC foam board

Comprehensive Support Services

Professional installation and debugging teams available
One-year equipment warranty with year-round spare parts supply
Continuous technical consultation and problem resolution
Assistance with import/export procedures and consignment
Production engineers available for operational support
Long-term cooperation opportunities
