200T Pressure High Automatic Perforating Machine for Max 20mm Thickness Gypsum Board Punching

200T Pressure High Automatic Perforating Machine for Max 20mm Thickness Gypsum Board Punching

Markenbezeichnung:	LVJOE
Modellnummer:	LV-CK01
MOQ:	1 Satz
Preis:	US $20000-80000
Versorgungsfähigkeit:	50 Sätze pro Jahr

Einzelheiten

Beschreibung des Produkts

Einzelheiten

Herkunftsort:

China

Zertifizierung:

ISO CE

Produktname:

Schallschutzplatten-Perforierausrüstung Hochgeschwindigkeits-Gipsplatten-Stanzmaschine

Stichwort:

Perforator für kontinuierliche Produktion von Gipskartonplatten

Druck:

80T, 160T, 200T

Verwendung:

Gipsplatten, MDF, HPL, Perforation von Faserzementplatten

Löcher:

Runde, Quadrat

Automatisches Niveau:

Hohes automatisches

Dicke:

Max. 20 mm

Garantie:

1 Jahr

Anwendung:

Innendecke und Trennwand

Besonderheit:

GEMEINSAM

Verpackung Informationen:

PE -Film verpackt

Versorgungsmaterial-Fähigkeit:

50 Sätze pro Jahr

Beschreibung des Produkts

Sound Insulation Board Perforating Equipment High Speed Plaster Board Punch Machine

High-performance gypsum board drilling equipment designed for precision perforation in various building materials.

Product Specifications

Pressure	80T, 160T, 200T
Usage	Gypsum Board, MDF, HPL, Fiber cement board perforation
Holes	Round, Square
Automatic Level	High automatic
Thickness	Max. 20mm

Technical Specifications

Punching pressure: 200 ton
Stroke: 30 mm
Max mold height closed: 260mm
Number of strokes: 50 times/minute
Slide surface: 210*1100mm
Working table: 300*1670mm
Spacing of both pole: 1350mm (load the max board width 1220mm)
Power of main motor: 22kw
Power of servo motor: 2.6kw (brand: Zhejiang yifeng)
Feeding accuracy: ±1mm
Maximum feeding rate: 100mm
Maximum feeding thickness: 20mm
Gross weight of machine: 11000kg
Overall dimension: 2300*1500*2300(H*L*W)

Applications

This perforation machine is designed for creating holes in various materials including gypsum ceiling board, MgO board, MDF, HPL, Fiber cement board, and metal sheets. Custom hole shapes are available to meet specific requirements. Comprehensive operational training is provided.
